Basic Info.
Model NO.
BZW-3.0+CM
Certification
CCC, ISO, CE
Warranty
24 Months
Automatic Grade
Automatic
Transport Package
Wooden
Specification
3500*1200*1700mm
Trademark
BOZWANG
Origin
Jiangsu Changzhou
HS Code
8479899990
Production Capacity
100set/Month
Packaging & Delivery
Package Size
350.00cm * 120.00cm * 170.00cm
Package Gross Weight
1100.000kg
Product Description
.BZW-3.0+CMAutomatic high precise double ends terminal crimping machine with receptacle housing inserting
Product description:
This equipment is upgrade of automatic high precise double ends terminal crimping machine ,mainly for power, automotive new energy industry wire harness processing. terminal receptacle housing inserting station added to the basic work line as integration of wire cutting, wire stripping and terminal crimping function. It realizes wire cutting, wire stripping, terminal crimping and receptacle housing inserting functions by one touch, which will improve the degree of automation and production efficiency.
Product features:
1. International appearance design, and tight and concise whole structure;
2.IPC controlling system, operating interface is simple and rational. The operation of the machine is easy to learn. All the parameters is easily set and stored. The images of operating indications are simple and direct;
3. Panasonic FP2 RTX network bus system, high precision, fast response, and monitoring in real time;
4. The crimping station is installed with imported servo motor, high crimping precision and stable performance;
5. The pneumatic parts are all imported SMC, high efficiency and stability with long life service;
6. Full closed loop flexible wire feeding system, rubber belt feeding device protects the surface of the wire from the damaging, increasing the feeding efficiency;
7. The optional barcode gun and printer can manage and store the data.;
8. The unqualified product can be eliminated and reclaimed to reach 100% qualified rate.
9. The receptacle housing feeding station is equipped with vibratory plate and orbit. Both receptacle housing clamp speed and feeding delay time are adjustable on touch screen, smartly match the proceeding of whole automatic work line.
Technical parameters:
1.Wire range: 0.3-6mm2(AWG9#-AWG23#) (Other size can be special ordered)
2.Cutting length: 60-10000mm(Other size can be special ordered)
3.Cutting precision: ±(0.2%*L+1)mm
4.Stripping length: 0.1-18.5mm
5.Feeding speed: Max. 8.0 m/s
6.Capacity:60-70pcs/min
7.Crimping force: 30KN
8.Power: 220V 50HZ
9. Air supply: 0.5 Mpa-0.7 Mpa,8m3/h
10. Weight: about 1100kg
11. Dimension: 3500*1200*1700mm
12. Detecting ability: wire knotting, wire lacking, terminal lacking, crimping pressure, air pressure, bare wire and terminal crimping lacking;
13. Applicator range: OTP applicator, European applicator and pneumatic applicator;
14. It can be installed with CFM, monitoring the crimping quality during the whole processing and 100% traceability.
15. Function: automatic wire cutting, wire stripping on single end/double ends/terminal crimping/receptacle housing inserting(housing type for 2.8,4.8,6.3mm faston terminals optional).
It can be installed with CFM, monitoring the crimping quality during the whole processing and 100% traceability.
Function: automatic wire cutting, wire single end striping and double end stripping/half stripping/ terminal crimping/seal threading, one end twisting and tinning, another end terminal crimping and seal inserting;
